PVX-130-R-ST-0000-000-10 Hyd Piston Pump, PVXS-130M04R00C1R01SKKASTC05A4C05A400000A000000000010
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Hydrokraft heavy-duty open-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 12030105 be shipped?
12030105 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 12030105 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 12030105 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 12030105, subject to availability and destination.
Danfoss PVX-130-R-ST-0000-000-10 Hyd Piston Pump, PVXS-130M04R00C1R01SKKASTC05A4C05A400000A000000000010, manufacturer part number 12030105. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Pump | Open loop pump |
| Displacement type | Variable |
| Series | X-series |
| Configuration | Single unit |
| Displacement | 130 ccm/rev |
| Basic Standard | Metric |
| Mounting Flange | ISO3019/2 160A2SW |
| Rotation direction | Clockwise |
| Max displacement set | Max Disp Adj Screw |
| Thru drive options | SAE C |
| Main port | SAE Port Metric Bolts |
| Main port orientation | Radial (side ports) |
| Main drive shaft end | ISO Straight key |
| Drive shaft seal config | Single shaft seal |
| Seal material | FKM with HP lubrication |
| Yoke position indicator | Hall Sensor 4-20mA + LED |
| Surface coating | Primer jet black RAL 9005 |
| Control type | Elec. flow control prop valve |
| Disp adj options | CETOP 3 proportional valve |
| Electronic amplifier | DIN rail module |
| Yoke displacement zone | Single side center A |
| Additional functions | Pressure limiter override (ST) |
| Pressure control options | None (depends on control type) |
| Power control | Not applicable |
| Pilot oil filter | None |
| V-valve_pilot oil sup | Internal pilot oil supply |
| Position monitoring | Not applicable |
| Electric motor type | Not applicable |
| Control voltage | Not applicable |
| Customer adjustment | None |
| Special feature | None |
| Design number | per data spec. in D. table 10 |
| IPM FRAME SIZE | PVX-130cc 10 design Pump |
| Model Code 1 | PVXS-130M04R00C1R01SKKASTC05A4 |
| Model Code 2 | C05A400000A000000000010 |
