Danfoss 12029665

Hyd Piston Pump PVX-250-R-LR-0000-000-10, PVX-250-R-LR-0000-000-10000A2F12000000000000010

MPN: 12029665
Category: Hydrokraft heavy-duty open-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 12029665?

Danfoss Hyd Piston Pump PVX-250-R-LR-0000-000-10, PVX-250-R-LR-0000-000-10000A2F12000000000000010, manufacturer part number 12029665. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Pump	Open loop pump
Displacement type	Variable
Series	X-series
Configuration	Single unit
Displacement	250 ccm/rev
Basic Standard	Metric
Mounting Flange	ISO3019/2 200A2SW
Rotation direction	Clockwise
Max displacement set	Max Disp Adj Screw
Thru drive options	None
Main port	SAE Port Metric Bolts
Main port orientation	Radial (side ports)
Main drive shaft end	ISO Straight key
Drive shaft seal config	Single shaft seal
Seal material	FKM
Yoke position indicator	Visual indicator
Surface coating	Primer jet black RAL 9005
Control type	Power control
Disp adj options	Not applicable
Electronic amplifier	No amplifier card / n/a
Yoke displacement zone	Single side center A
Additional functions	Pressure limiter override (LR)
Pressure control options	Remote port
Power control	kW at 1500 ppm
Pilot oil filter	None
V-valve_pilot oil sup	No venting valve
Position monitoring	Not applicable
Electric motor type	Not applicable
Control voltage	Not applicable
Customer adjustment	None
Special feature	None
Design number	per data spec. in D. table 10
Brand	Danfoss
IPM FRAME SIZE	PVX-250cc 10 design Pump
Model Code 1	PVX-250-R-LR-0000-000-10
Model Code 2	000A2F12000000000000010
Sub brand	Hydrokraft
