PVX-250-R-DF-0139-175-10 Hyd Piston Pump, PVX-250-R-DF-0139-175-10000A0000000000013917510
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Hydrokraft heavy-duty open-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 12027632 be shipped?
12027632 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 12027632 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 12027632 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 12027632, subject to availability and destination.
Danfoss PVX-250-R-DF-0139-175-10 Hyd Piston Pump, PVX-250-R-DF-0139-175-10000A0000000000013917510, manufacturer part number 12027632. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Pump | Open loop pump |
| Displacement type | Variable |
| Series | X-series |
| Configuration | Single unit |
| Displacement | 250 ccm/rev |
| Basic Standard | Metric |
| Mounting Flange | ISO3019/2 200A2SW |
| Rotation direction | Clockwise |
| Max displacement set | Fix mech stop side A |
| Thru drive options | None |
| Main port | SAE Port Metric Bolts |
| Main port orientation | Axial (in-line rear) |
| Main drive shaft end | ISO Straight key |
| Drive shaft seal config | Single shaft seal |
| Seal material | FKM |
| Yoke position indicator | Visual indicator |
| Surface coating | Primer jet black RAL 9005 |
| Control type | Pressure compensator |
| Disp adj options | Not applicable |
| Electronic amplifier | No amplifier card / n/a |
| Yoke displacement zone | Single side center A |
| Additional functions | None / not applicable |
| Pressure control options | None (depends on control type) |
| Power control | Not applicable |
| Pilot oil filter | None |
| V-valve_pilot oil sup | No venting valve |
| Position monitoring | Not applicable |
| Electric motor type | Not applicable |
| Control voltage | Not applicable |
| Customer adjustment | Per data Spec. in CA table no. |
| Special feature | Per data Spec.in SF table no. |
| Design number | per data spec. in D. table 10 |
| Brand | Danfoss |
| IPM FRAME SIZE | PVX-250cc 10 design Pump |
| Model Code 1 | PVX-250-R-DF-0139-175-10 |
| Model Code 2 | 000A0000000000013917510 |
| Sub brand | Hydrokraft |
