Danfoss 12027438

PVM141MR13GS20000000000AB-0000, PVM141MR13GS20000000000AB-0000

MPN: 12027438
Category: Medium-duty open-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 12027438?

Danfoss PVM141MR13GS20000000000AB-0000, PVM141MR13GS20000000000AB-0000, manufacturer part number 12027438. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

CODE TITLE	VARIABLE DISPLACEMENT OPEN CIRCUIT PISTON PUMPS
DISPLACEMENT	141.0 cm3/r [8.60 in3/r] (230 bar MAX)
Valve plate	HIGH SPEEDS VERSION
Input rotation	CLOCKWISE (RIGHTHAND)
INPUT SHAFT	SAE J744-44-1, SAE D, STRAIGHT KEYED (MODEL 131)
Mounting Flange	SAE J744-127-4 (C 4-BOLT)(MODELS 057,074,098 AND 131)
MAIN PORT LOCATION	SIDE
PORT OPTIONS	SAE J518 FLANGE PORTS, SAE AUXILIARY PORTS
CONTROL	NONE
PRESSURE COMP SETTING	NONE
FLOW COMP SETTING	NONE
POWER CONTROL SETTING	NONE
Auxiliary mounting	NONE (NON-THROUGH DRIVE)
Paint	BLACK [DEFAULT]
DESIGN CODE	B
DIFFERENTIATOR	-
PUMP SPECIAL FEATURES	ADJUSTABLE MAX DISPLACEMENT STOP [DEFAULT]
COMPENSATOR SPECIAL FEATURES	NONE
Customer identification	NONE
IPM FRAME SIZE	PVM Code B 141cc Pump
Model Code 1	PVM141MR13GS20000000000AB-0000
Proposition 65	Cancer and Reproductive Harm
