Danfoss 12007842

PVW-500-R-SP-0000-000-15Hyd. Piston Pump, PVWS-500M08R00P1R01SKSASPD03A0

MPN: 12007842
Category: Hydrokraft heavy-duty open-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 12007842?

Danfoss PVW-500-R-SP-0000-000-15Hyd. Piston Pump, PVWS-500M08R00P1R01SKSASPD03A0, manufacturer part number 12007842. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Pump	Open loop pump
Displacement type	Variable
Series	W-series
Configuration	Single unit
Displacement	500 ccm/rev
Basic Standard	Metric
Mounting Flange	ISO3019/2-250B4HW
Rotation direction	Clockwise
Max displacement set	Max disp adj screw
Thru drive options	Pilot pump 8cc
Main port	SAE port metric bolts
Main port orientation	Radial (side ports)
Main drive shaft end	ISO Straight Key
Drive shaft seal config	Single shaft seal
Seal material	FKM with HP lubrication
Yoke position indicator	Current &+Visual indicator (new)
Surface coating	Primer jet black RAL 9005
Control type	Proportional valve
Disp adj options	CETOP 3 proportional valve KBSDG4V-3 with OBE
Electronic amplifier	ER9.3 Amplifier
Yoke displacement zone	Single Side Center A for DF, LR, SP. ST, DP and ES. No pressure sensor one side for PQ Control.
Additional functions	None / not applicable
Pressure control options	Inc Pilot Relief Valve and Remote Port for SP
Power control	None/ n/a (depend. on control)
Pilot oil filter	Filter with electrical Indicator
V-valve_pilot oil sup	No venting valve
Position monitoring	Not applicable
Electric motor type	Not applicable
Control voltage	Not applicable
Customer adjustment	None
Special feature	None
Design number	Per data spec. in D. table 15
Brand	Danfoss
IPM FRAME SIZE	PVW-500cc Pump
Model Code 1	PVWS-500M08R00P1R01SKSASPD03A0
Sub brand	Hydrokraft
