Danfoss 12002151

KBDG5V-7-33C130N65-E-H-M2-PE7-H1-20, KBDG5V733C130N65EHM2PE7H120

MPN: 12002151
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 12002151?

Danfoss KBDG5V-7-33C130N65-E-H-M2-PE7-H1-20, KBDG5V733C130N65EHM2PE7H120, manufacturer part number 12002151. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Port flow LPM	130.00
A Port flow USGPM	34.00
Actuation Type	Solenoid controlled pilot operated
B Port flow LPM	65.00
B Port flow USGPM	17.00
Brand	Vickers by Danfoss
Build orientation	Standard as per ANSI B93 9
Build type	Spring centered
Coil voltage	24 Volt DC
Command input	4-20mA Control signal
Communication protocol	None
Design Series	20 Series
Electrical Connection	Electrical (PE7) 7 pin electrical plug with mating half
Feedback sensor	No
Fluid Cleanliness	17/15/12 micron
Fluid compatibility	Antiwear hydraulic oils and non alkyl-based Phosphate Esters
Interface	ISO4401-07/NFPA D07/CETOP 7/NG16
Manual override	Water-resistant
Maximum pressure BAR	350
Maximum pressure PSI	5000
Metering	Meter in / meter out
Model Code 1	KBDG5V733C130N65EHM2PE7H120
On board electronics	Yes
Performance	Standard
Pilot drain	External
Pilot supply	External
Product height in	7.690
Product height mm	195.326
Product length in	10.150
Product length mm	257.810
Product width in	3.650
Product width mm	92.71
ProFX compatible	No
Reducer module	No
Reverse flow check	No
Seal type	Viton
Special features	None
Spool Type	P blocked, A & B to tank
Stage	Two stage
Symmetric flow	No
Tank port rating BAR	350
Tank port rating PSI	5000
Valve Mount Type	Subplate
Valve type	Proportional directional
Working temp max C	70
Working temp max F	158
Working temp min C	-20
Working temp min F	-4
