PVW-500-L-DF-0517-000-15 REAR HYD PUMP, PVWR-500M08L40B1R02SQVADF000A0S00000000051700015
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Hydrokraft heavy-duty open-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 11372264 be shipped?
11372264 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11372264 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11372264 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11372264, subject to availability and destination.
Danfoss PVW-500-L-DF-0517-000-15 REAR HYD PUMP, PVWR-500M08L40B1R02SQVADF000A0S00000000051700015, manufacturer part number 11372264. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Pump | Open loop pump |
| Displacement type | Variable |
| Series | W-series |
| Configuration | Rear unit |
| Displacement | 500 ccm/rev |
| Basic Standard | Metric |
| Mounting Flange | ISO3019/2-250B4HW |
| Rotation direction | Counter-clockwise |
| Max displacement set | Fix mech stop side A |
| Thru drive options | SAE B |
| Main port | SAE port metric bolts |
| Main port orientation | Radial (side ports) |
| Main drive shaft end | ISO Spline |
| Drive shaft seal config | Single shaft seal |
| Seal material | FKM front bearing flushing + HP lubrication |
| Yoke position indicator | Visual indicator |
| Surface coating | Primer jet black RAL 9005 |
| Control type | Pressure compensator |
| Disp adj options | Not applicable |
| Electronic amplifier | No amplifier card / n/a |
| Yoke displacement zone | Single Side Center A for DF, LR, SP. ST, DP and ES. No pressure sensor one side for PQ Control. |
| Additional functions | None / not applicable |
| Pressure control options | Slow upstroke screw adjustment |
| Power control | None/ n/a (depend. on control) |
| Pilot oil filter | None |
| V-valve_pilot oil sup | No venting valve |
| Position monitoring | Not applicable |
| Electric motor type | Not applicable |
| Control voltage | Not applicable |
| Customer adjustment | per Data Specified in CA Table No |
| Special feature | None |
| Design number | Per data spec. in D. table 15 |
| Brand | Danfoss |
| IPM FRAME SIZE | PVW-500cc Pump |
| Model Code 1 | PVWR-500M08L40B1R02SQVADF |
| Model Code 2 | 000A0S00000000051700015 |
| Sub brand | Hydrokraft |
