Danfoss 11370368

PVM098ER11GS2F000200000AB-0000, PVM098ER11GS2F000200000AB-0000

MPN: 11370368
Category: Medium-duty open-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11370368?

Danfoss PVM098ER11GS2F000200000AB-0000, PVM098ER11GS2F000200000AB-0000, manufacturer part number 11370368. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

CODE TITLE	VARIABLE DISPLACEMENT OPEN CIRCUIT PISTON PUMPS
DISPLACEMENT	98.3 cm3/r [6.00 in3/r] (315 bar MAX)
Valve plate	INDUSTRIAL (1800 r/min MAX)
Input rotation	CLOCKWISE (RIGHTHAND)
INPUT SHAFT	SAE J744-32-4, SAE C, 14T SPLINE (MODEL 057 074,098 AND 131)
Mounting Flange	SAE J744-127-4 (C 4-BOLT)(MODELS 057,074,098 AND 131)
MAIN PORT LOCATION	SIDE
PORT OPTIONS	SAE J518 FLANGE PORTS, SAE AUXILIARY PORTS
CONTROL	INDUSTRIAL CONTROL (PRESSURE COMPENSATED) (MODEL 057 THRU 141)
PRESSURE COMP SETTING	NONE
FLOW COMP SETTING	20±1 bar [290±14.5 lbf/in2][DEFAULT]
POWER CONTROL SETTING	NONE
Auxiliary mounting	NONE (NON-THROUGH DRIVE)
Paint	BLACK [DEFAULT]
DESIGN CODE	B
DIFFERENTIATOR	-
PUMP SPECIAL FEATURES	ADJUSTABLE MAX DISPLACEMENT STOP [DEFAULT]
COMPENSATOR SPECIAL FEATURES	NONE
Customer identification	NONE
Brand	Vickers by Danfoss
IPM FRAME SIZE	PVM Code B 98cc Pump
Model Code 1	PVM098ER11GS2F000200000AB-0000
Proposition 65	Cancer and Reproductive Harm
