TVW-500-L-SP-0515-751-10 HYD PISTON PUMP, TVWF-500M08L0000H1R02SQKA30SPC03C300000000100H051575110
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Hydrokraft heavy-duty closed-circuit piston pumps |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 11369527 be shipped?
11369527 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11369527 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11369527 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11369527, subject to availability and destination.
Danfoss TVW-500-L-SP-0515-751-10 HYD PISTON PUMP, TVWF-500M08L0000H1R02SQKA30SPC03C300000000100H051575110, manufacturer part number 11369527. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Pump | Transmission pump |
| Displacement type | Variable |
| Series | W-Series |
| Configuration | Front unit |
| Displacement | 500 ccm/rev |
| Basic Standard | Metric |
| Mounting Flange | ISO3019/2-250B4HW |
| Rotation direction | Counter-clockwise |
| Max displacement set | Max disp adj screw |
| Thru drive options | ISO 200B4 |
| Main port | Sae port metric bolts |
| Main port orientation | Radial (side ports) |
| Main drive shaft end | ISO Spline |
| Drive shaft seal config | Single shaft seal |
| Seal material | FKM front bearing flushing + HP lubrication |
| Yoke position indicator | Hall Sensor 4-20mA + LED |
| Surface coating | Primer jet black RAL 9005 |
| Transmission circuit | with trans. circuit, without filter. ind., with HP relief |
| Zero position valve | No zero position valve |
| Control type | Proportional valve |
| Disp adj options | CETOP 3 prop.Valve KDG4V-3 |
| Electronic amplifier | ER9.3 Amplifier for SP and Prop.Relief valve with DIN43650.Plug. Incl. ER9.3 for DP |
| Yoke displacement zone | Over center |
| Additional functions | Pressure limiter overriding function side A and B |
| Pressure control options | Standard screw adjustment (DP, ES = n/a) |
| Power control | Not applicable |
| Pilot oil filter | None |
| Fail safe valve | Solenoid valve |
| Position monitoring | Not applicable |
| Electric motor type | Not applicable |
| Control voltage | 24 V DC |
| Customer adjustment | per Data Specified in CA Table No |
| Special feature | Per data Spec.in SF table no. |
| Design number | Per data spec. in D. table 10 |
| Brand | Danfoss |
| IPM FRAME SIZE | TVW-500cc Pump |
| Model Code 1 | TVWF-500M08L0000H1R02SQKA30SP |
| Model Code 2 | C03C300000000100H051575110 |
| Sub brand | Hydrokraft |
