Danfoss 11363154

PVM020ER05CS1C230110001AB-0000, PVM020ER05CS1C230110001AB-0000

MPN: 11363154
Category: Medium-duty open-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11363154?

Danfoss PVM020ER05CS1C230110001AB-0000, PVM020ER05CS1C230110001AB-0000, manufacturer part number 11363154. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

CODE TITLE	VARIABLE DISPLACEMENT OPEN CIRCUIT PISTON PUMPS
DISPLACEMENT	21.1 cm3/r [1.29 in3/r] (230 bar MAX)
Valve plate	INDUSTRIAL (1800 r/min MAX)
Input rotation	CLOCKWISE (RIGHTHAND)
INPUT SHAFT	SAE J744-22-1, SAE B, STRAIGHT KEYED (MODEL 010, 013, 018 AND 045)
Mounting Flange	SAE J744-101-2(B 2-BOLT) (MODELS 010, 013, 018 AND 045)
MAIN PORT LOCATION	SIDE
PORT OPTIONS	SAE J514 TUBE PORTS, SAE AUXILIARY PORTS (Model 010, 013, 018 AND 045)
CONTROL	PRESSURE AND FLOW COMPENSATOR WITH PLUGGED ORIFICE
PRESSURE COMP SETTING	230±4 bar [3335±58 lbf/in2][DEFAULT][OVERBORE CC]
FLOW COMP SETTING	11±1 bar [159.5±14.5 lbf/in2][DEFAULT]
POWER CONTROL SETTING	NONE
Auxiliary mounting	AUXILIARY A-MOUNT WITH COVER PLATE AND NO COUPLER
Paint	BLACK [DEFAULT]
DESIGN CODE	B
DIFFERENTIATOR	-
PUMP SPECIAL FEATURES	ADJUSTABLE MAX DISPLACEMENT STOP [DEFAULT]
COMPENSATOR SPECIAL FEATURES	NONE
Customer identification	NONE
Brand	Vickers by Danfoss
IPM FRAME SIZE	PVM Code B 20cc Pump
Model Code 1	PVM020ER05CS1C230110001AB-0000
