Danfoss 11354030

PRV1-10-K-0-6/5, PRV1-10-K-0-6-5

MPN: 11354030
Category: Cartridge valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11354030?

Danfoss PRV1-10-K-0-6/5, PRV1-10-K-0-6-5, manufacturer part number 11354030. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Adjustment type	Knob
Brand	Danfoss
Cavity	C-10-3
Factory set pressrue BAR	35.000
Factory set pressrue PSI	500.000
Flow rate GPM	4.00
Flow rate LPM	15.000
Fluid compatibility	MIL-H-5606, SAE10, SAE20, etc
Function	Pressure Reducing/Relieving
Housing	No
Housing material	None
Installation type	Screw-in Cartridge
Leakage	164 cc/min
Max working pressure BAR	41.000
Max working pressure PSI	600.000
Min working pressure BAR	7.000
Min working pressure PSI	100.000
Model Code 1	PRV1-10-K-0-6-5
Number of housing ports	3
Number of valve ports	3
Operating temperature	-40 C to 120 C (-40 to 248 F)
Operation	Direct acting
Port size	None
Port type	Cartridge Only
Pressure rating BAR	210.000
Recommended filtration level	18/16/13
Seal type	Buna-N
Special features	None
Style	Spool
