Home / Danfoss (Drives) / PVW-180-R-SP-0000-000-20 Hyd Piston Pump, PVW-180-R-SP-0000-000-20

Available on request

PVW-180-R-SP-0000-000-20 Hyd Piston Pump, PVW-180-R-SP-0000-000-20

Name: PVW-180-R-SP-0000-000-20 Hyd Piston Pump, PVW-180-R-SP-0000-000-20
Brand: Danfoss (Drives)
SKU: 11345946

MPN: 11345946 · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Hydrokraft heavy-duty open-circuit piston pumps
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 11345946 be shipped?

11345946 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11345946 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11345946 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11345946, subject to availability and destination.

Danfoss PVW-180-R-SP-0000-000-20 Hyd Piston Pump, PVW-180-R-SP-0000-000-20, manufacturer part number 11345946. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Pump	Open loop pump
Displacement type	Variable
Series	W-Series
Configuration	Single unit
Displacement	180 ccm/rev
Basic Standard	Metric
Mounting Flange	ISO3019/2-160B4HW
Rotation direction	Clockwise
Max displacement set	Max Disp Adj Screw
Thru drive options	None
Main port	SAE Port Metric Bolts
Main port orientation	Radial (side ports)
Main drive shaft end	ISO Straight key
Drive shaft seal config	Single shaft seal
Seal material	FKM
Yoke position indicator	Hall Sensor 4-20mA + LED
Surface coating	Primer jet black RAL 9005
Control type	Proportional valve
Disp adj options	CETOP 3 prop.Valve KDG4V-3
Electronic amplifier	ER9.3 Amplifier
Yoke displacement zone	Single s.(dep. on control typ)
Additional functions	None / not applicable
Pressure control options	None (depends on control type)
Power control	None/ n/a (depend. on control)
Pilot oil filter	Filter with el. Indicator
V-valve_pilot oil sup	No venting valve
Position monitoring	Not applicable
Electric motor type	Not applicable
Control voltage	Not applicable
Customer adjustment	None
Special feature	None
Design number	Per data spec. in D. table 20
Brand	Danfoss
IPM FRAME SIZE	PVW-180cc Pump
Model Code 1	PVW-180-R-SP-0000-000-20
Sub brand	Hydrokraft
