Danfoss 11345505

V10HS01B05BB001A00ZAR000AZ31, V10HS01B05BB001A00ZAR000AZ31

MPN: 11345505
Category: Industrial vane pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11345505?

Danfoss V10HS01B05BB001A00ZAR000AZ31, V10HS01B05BB001A00ZAR000AZ31, manufacturer part number 11345505. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Seal type	NBR Seals
PUMP TYPE	VANE PUMP
Series	High Pressure
Cover type	STANDARD COVER
Mounting type	2 BOLT FLANGE SAE-A SIZE
INLET PORT TYPE	BSP THREAD PER DS1106
RING CAPACITY	5 GPM
OUTLET PORT TYPE	BSP THREAD PER DS1104
SHAFT SEAL AND BEARING	SINGLE LIP SEAL&SEALED BEARING
Shaft type	STRAIGHT KEY - 3/16,MAJOR DIA-0.75, EXTENSION-1.75
OUTLET COVER PORT ORIENTATION	OPPOSITE TO INLET PORT
FLOW RATE THRU ORF IN COVER	No Flow
PRESSURE SETTING	NO PRESSURE SETTING
DESIGN CODE	31 Design
Shaft rotation	RH CW ROTATION VIEWED FROM SHAFT END
SPECIAL FEATURE SUFFIX	No special feature
Brand	Vickers by Danfoss
Model Code 1	V10HS01B05BB001A00ZAR000AZ31
