Danfoss 11345297

PVW-360-L-SP-0000-000-14 Hyd Piston Pump, PVWS-360M07L00B1R01SVPASPC03A0

MPN: 11345297
Category: Hydrokraft heavy-duty open-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11345297?

Danfoss PVW-360-L-SP-0000-000-14 Hyd Piston Pump, PVWS-360M07L00B1R01SVPASPC03A0, manufacturer part number 11345297. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Pump	Open loop pump
Displacement type	Variable
Series	W-Series
Configuration	Single unit
Displacement	360 ccm/rev
Basic Standard	Metric
Mounting Flange	ISO3019/2-200B4HW
Rotation direction	Counter-clockwise
Max displacement set	Max Disp Adj Screw
Thru drive options	SAE B
Main port	SAE Port Metric Bolts
Main port orientation	Radial (side ports)
Main drive shaft end	ISO Straight key
Drive shaft seal config	Single shaft seal
Seal material	FKM
Yoke position indicator	Voltage indicator
Surface coating	Primer jet black RAL 9005
Control type	Proportional valve
Disp adj options	CETOP 3 prop.Valve KDG4V-3
Electronic amplifier	ER9.3 Amplifier
Yoke displacement zone	Single s.(dep. on control typ)
Additional functions	None / not applicable
Pressure control options	None (depends on control type)
Power control	None/ n/a (depend. on control)
Pilot oil filter	None
V-valve_pilot oil sup	No venting valve
Position monitoring	Not applicable
Electric motor type	Not applicable
Control voltage	Not applicable
Customer adjustment	None
Special feature	None
Design number	Per data spec. in D. table 14
Brand	Danfoss
IPM FRAME SIZE	PVW-360cc Pump
Model Code 1	PVWS-360M07L00B1R01SVPASPC03A0
Sub brand	Hydrokraft
