Danfoss 11323612

GEAR MOTOR GR2 BIDIRECT FIXED DISPL

MPN: 11323612
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 11323612?

Danfoss GEAR MOTOR GR2 BIDIRECT FIXED DISPL, manufacturer part number 11323612. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 7,5 cc
Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4 CO01
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Inlet on body - Outlet on body - Drain on cover in vertical position driven gear side
Inlet size	1-1/16-12UN
Mark position	Sticker on the body
Mark type	Standard Marking
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	3/4-16UNF
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for motor with side drain in vertical axis 9/16-18UNF-2B
ROTATION	Bidirectional
Screws	Screws standard
Seals	Standard seal
Slash separator	Slash
Valve setting	without setting
