PVBS32-SPOOL-Z-C25/F25/F25/C25-CV-FLB
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Compensated directional control valves |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 11276367 be shipped?
11276367 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11276367 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11276367 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11276367, subject to availability and destination.
Danfoss PVBS32-SPOOL-Z-C25/F25/F25/C25-CV-FLB, manufacturer part number 11276367. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| A->T Control Type | Flow |
| A->T Flow Rate | 25 |
| A->T Function in Neutral | Blocked (Closed) |
| B->T Control Type | Flow |
| B->T Flow Rate | 25 |
| B->T Function in Neutral | Blocked (Closed) |
| Certification | ISO13849 Compliant |
| Ex Application | N/A |
| Float Direction | B Port |
| Marking | N/A |
| Minimum Float Position | 6 |
| Nominal Diameter | Standard |
| Nominel Max Position A | 5.5 |
| Nominel Max Position B | 5.5 |
| P-> A Flow Rate | 25 |
| P-> B Flow Rate | 25 |
| P->A Control Type | Flow |
| P->B Control Type | Flow |
| Pilot Pressure Full Stroke | 5.5 bar |
| Pilot Pressure Neutral | 4.0 bar |
| Pressure Control P->A | N/A |
| Pressure Control P->B | N/A |
| Primer | Passivation - Transparent |
| Product Category | Standard Part |
| Product type | Spool |
| Proposition 65 | Cancer and Reproductive Harm |
| Spool Characteristic A | Progressive |
| Spool Characteristic B | Progressive |
| Spool Data | N/A |
| Spool Deadband | 0.8 |
| Spool Interface | PVBZ32 LS Shuttle |
| Spool Option A | Tensionbar |
| Spool Option B | Plug |
