Danfoss 11273605

GEAR PUMP GR3 FIXED DISPL

MPN: 11273605
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11273605?

Danfoss GEAR PUMP GR3 FIXED DISPL, manufacturer part number 11273605. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

B: Displacement	Displacement 48 cc
C: Rotation	Product with counter-clockwise rotation
D_SIZE GROUP3	Group3-from 16 to 90cc displ
D: Project version	Standard Version of Project
E_VALVE GROUP3	Without valve
E: Mounting flange	Pilot D50.8+4 holes+spec.sh
F_DRAIN GROUP3	Standard or no drain
F: Drive gear	Taper 1:8 - M14 x 1,5 - Key = 4 ; rear spline DIN 5482 22 x 19 L=16,5 CO41-CO42
G: Rear cover	Not assigned (with intermediate flange instead cover)
H: Inlet size	27x1 GAS
I: Outlet size	20x3/4 GAS
J: Ports position	Standard from catalogue
K: Seals	Two opposite shaft seal
L: Screws	Screws standard
M: Valve setting	without setting
N: Mark type	Standard Marking
O-Ring, Inside Diameter	Slash
O: Mark position	Position Marking standard
Proposition 65	Cancer and Reproductive Harm
Slash separator	Slash
