Home / Danfoss (Drives) / GearMe single stage / Danfoss 11262734

Danfoss 11262734

GEAR PUMP GR2 FIXED DISPL

MPN: 11262734
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11262734?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11262734. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	2
Displacement	Displacement 22 cc
Drive gear	Splined SAE J498-11T-16/32-Dp Class 1FIT - ( rear tang 8 x 19,94 x L=6,5 ) (type 36)
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Standard
Inlet size	20x40xM6
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange with pilot Ø36,5 mm and 4 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	15x35xM6
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Not assigned (with intermediate flange instead cover)
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Hi.Torque-Main stage
Slash separator	Slash
Valve setting	without setting

11262734: frequently asked questions

When can 11262734 be shipped?

11262734 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11262734 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11262734 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11262734, subject to availability and destination.
