Danfoss 11261738

TANDEM GEAR PUMP GR2 + GR1

MPN: 11261738
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11261738?

Danfoss TANDEM GEAR PUMP GR2 + GR1, manufacturer part number 11261738. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.2+1 family	SKW2NN + SNP1NN
B: 1st stage displacement	Displacement 25 cc
C: 2nd stage displacement	Displacement 1,7 cc
D: Rotation	Product with clockwise rotation
E: Project version	Standard ( without intermediate flange )
F: Mounting flange	Flange SAE A, pilot D.82,55 and 2 holes for bolts with seal on pilot diameter (BAW)
G: Drive gear	SAE J498-11T-16/32+DIN5482-L14
H: Rear cover	Std Cover for pump
I: 1st stage inlet size	1-5/16-12UN
J: 1st stage outlet size	7/8-14UNF
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	3/4-16UNF
M: 2nd stage outlet size	9/16-18UNF
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard from catalogue
OC DELIMITER (-)	-
P: Screws	Standard from catalogue
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without valve
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Std Position Marking
Slash separator	Slash
