Home / Danfoss (Drives) / Compensated directional control valves / Danfoss 11259585

Danfoss 11259585

PVBS32-SPOOL-C25/F25/F15/C15-CV

MPN: 11259585
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11259585?

Danfoss PVBS32-SPOOL-C25/F25/F15/C15-CV, manufacturer part number 11259585. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A->T Control Type	Flow
A->T Flow Rate	25
A->T Function in Neutral	Blocked (Closed)
B->T Control Type	Flow
B->T Flow Rate	15
B->T Function in Neutral	Blocked (Closed)
Certification	ISO13849 Compliant
Ex Application	N/A
Float Direction	N/A
Marking	N/A
Minimum Float Position	N/A
Nominal Diameter	Standard
Nominel Max Position A	7.2
Nominel Max Position B	7.2
P-> A Flow Rate	25
P-> B Flow Rate	15
P->A Control Type	Flow
P->B Control Type	Flow
Pilot Pressure Full Stroke	5.5 bar
Pilot Pressure Neutral	4.0 bar
Pressure Control P->A	N/A
Pressure Control P->B	N/A
Primer	N/A
Product Category	Phase Out
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Spool Characteristic A	Progressive
Spool Characteristic B	Progressive
Spool Data	N/A
Spool Deadband	1.5
Spool Interface	PVB32 LS Shuttle
Spool Option A	Tensionbar
Spool Option B	Plug
