Danfoss 11250530

GEAR PUMP GR2 FIXED DISPL WITH VALVE

MPN: 11250530
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11250530?

Danfoss GEAR PUMP GR2 FIXED DISPL WITH VALVE, manufacturer part number 11250530. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	2
Displacement	Displacement 11 cc
Drive gear	SAE J498-13T-16/32
E_VALVE GROUP2	Relief valve with internal drain
F_DRAIN GROUP2	Standard
Inlet size	1-1/16-12UN
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	SAE B pilot D101,6+2 holes
O-Ring, Inside Diameter	Slash
Outlet size	7/8-14UNF
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for pump per relief valve
ROTATION	Product with clockwise rotation
Screws	Product with galvanized assembly screws ( +nuts, washers or cap nuts if listed on the Bill of Material )
Seals	Standard seal
Single Stage Family	Gr2 Hi.Torque Pump-Int.dr.RV
Slash separator	Slash
Valve setting	Setting relief valve, velocity of product per checked setting 3000 rpm and pressure 210 bar with oil ISO VG68 a 40°-50°C
