Danfoss 11248400

PUMP-VAR DISPL, 90PV100

MPN: 11248400
Category: Mobile closed-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11248400?

Danfoss PUMP-VAR DISPL, 90PV100, manufacturer part number 11248400. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

F: DISPLACEMENT LIMITATION	No Limiters
G: END CAP PORTS	twin ports
H: CHARGE PUMP	20 cc/rev
J: AUXILIARY MOUNTING PAD	SAE-B with 13 teeth coupling
K: CHARGE PRESSURE SETTING	34 bar
K: CHARGE PRS RELIEF	34 bar
L: SHAFT OPTIONS	splined shaft , 14 teeth, pitch = 12 / 24
M: CONTROL	A5: EDC 24V
N: FILTRATION	pressure integral (long filter)
P: HIGH PRESSURE REGULATION	Port A & B: fast response PL, up to 450 bar settings
Proposition 65	Cancer and Reproductive Harm
Series 90 Displacement	100 Cubic Centimeters per Revolution
Series 90 Product Line	Series 90
Series 90 Rotation	Clockwise (Right hand) Rotation
T: CONTROL ORIFICES	F4: P=0.81 A+B=2.5 TA+TB=NONE
W: SPECIAL HARDWARE FEATURES	FBM:CP15+0.5VP H1EDC
Y: HIGH PRESSURE SETTING A	Port A = 380 Bar / 5510 PSI
Y: HIGH PRS SETTING PORT A	Port A = 380 Bar / 5510 PSI
Z: HIGH PRESSURE SETTING B	Port B = 380 Bar / 5510 PSI
Z: HIGH PRS SETTING PORT B	Port B = 380 Bar / 5510 PSI
