Danfoss 11247200
GEAR MOTOR GR2 FAN DRIVE WITH VALVE
- MPN
- 11247200
- Category
- Gear motors
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 11247200?
Danfoss GEAR MOTOR GR2 FAN DRIVE WITH VALVE, manufacturer part number 11247200. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| D_SIZE GROUP2 | 2 |
| Displacement | Displacement 25 cc |
| Drive gear | Taper 1:8 - M12 x 1,25 - Key = 4 CO01 |
| E_VALVE GROUP2 | Proportional Valve with internal drain and anti-cavitation check valve on the bearings |
| F_DRAIN GROUP2 | Standard |
| Inlet size | Without inlet |
| Mark position | Position Marking standard (on the top in relation to drive gear) |
| Mark type | Standard Marking |
| Mounting flange | Flange with pilot Ø36,5 mm and 4 holes for bolts |
| O-Ring, Inside Diameter | Slash |
| Outlet size | 3/4 GAS |
| Ports position | Standard from catalogue |
| Project version | Generation II |
| Proposition 65 | Cancer and Reproductive Harm |
| Rear cover | Cover for motor per proportional valve and axial drain 9/16-18UNF-2B |
| ROTATION | Product with clockwise rotation |
| Screws | Screws standard |
| Seals | Standard seal |
| Single Stage Family | Gr2 Mot.ISIS-CI Cov+In.7/8-14 |
| Slash separator | Slash |
| Valve setting | Setting proportional valve, type of connector 24 DT Volt and pressure 170 bar with oil ISO VG68 a 40°-50°C |
