Danfoss 11241927

TANDEM GTANDEM GEAR PUMP GR2 FIXED DISPL

MPN: 11241927
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11241927?

Danfoss TANDEM GTANDEM GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11241927. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.2 family	SKW2NN+SNP2NN
B: 1st stage displacement	Displacement 14 cc
C: 2nd stage displacement	Displacement 11 cc
D: Rotation	Product with clockwise rotation
E: Project version	Standard ( without intermediate flange )
F: Mounting flange	SAE B pilot D101,6+2 holes
G: Drive gear	SAE J498-13T-16/32+Tang
H: Rear cover	Cover for pump with holes M5
I: 1st stage inlet size	20x40xM6
J: 1st stage outlet size	15x35xM6
K: 1st stage ports position	Port type Bx-Bx for flange SAE-A as per catalogue (inverted std. position from flange to cover)(LCX)
L: 2nd stage inlet size	20x40xM6
M: 2nd stage outlet size	15x35xM6
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without setting
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Std Position Marking
Slash separator	Slash
