Danfoss 11235233

TRIPLE GEAR PUMP=GR2+GR2+GR1

MPN: 11235233
Category: GearMe modular three stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11235233?

Danfoss TRIPLE GEAR PUMP=GR2+GR2+GR1, manufacturer part number 11235233. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A_FAMILY GR2+2+1	SNW2NN+SNO2NN+SNP1NN
B: 1st stage displacement	Displacement 8,0 cc
C: 2nd stage displacement	Displacement 8,0 cc
D: 3rd stage displacement	Displacement 1,2cc
E: Rotation	Right rotation
F: Project version	Interm.flange-different Gr
G_FLANGE GR1+1+1	Slash
G: Mounting flange	Flange-SAE A-pilot D82,55+2 holes for bolts
H: Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT+Rear tang 8x17,46xL6,5 SC46
I: Rear cover	Std Cover for pump
J: 1st stage inlet size	1/2 GAS
K: 1st stage outlet size	1/2 GAS
L: 1st stage ports position	Std from catalogue
M: 2nd stage inlet size	1/2 GAS
N: 2nd stage outlet size	1/2 GAS
O-Ring, Inside Diameter	Slash
O: 2nd stage ports position	Std from catalogue
OC DELIMITER (-)	-
P: 3rd stage inlet size	3/8 GAS
Proposition 65	Cancer and Reproductive Harm
Q: 3rd stage outlet size	3/8 GAS
R: 3rd stage ports position	Std from catalogue
S: Seals	Std seal
Slash separator	Slash
T: Screws	DACROMET/GEOMET screws+nuts-washers-cap+nuts galvanized listed in BOM (LML)
U: Valve setting	without setting
V: Mark type	Std Sauer Danfoss Marking
W: Mark position	Std mark position
