Danfoss 11234293
GEAR PUMP GR2 FIXED DISPL
- MPN
- 11234293
- Category
- GearMe single stage
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 11234293?
Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11234293. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| D_SIZE GROUP2 | 2 |
| Displacement | Displacement 11 cc |
| Drive gear | Splined SAE J498-9T-16/32-Dp Class 1FIT -SC06 |
| E_VALVE GROUP2 | Without Valve |
| F_DRAIN GROUP2 | Standard |
| Inlet size | 1 GAS |
| Mark position | Position Marking standard (on the top in relation to drive gear) |
| Mark type | Standard Marking |
| Mounting flange | Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts |
| O-Ring, Inside Diameter | Slash |
| Outlet size | 12x17,48x38,1xM8 |
| Ports position | Standard from catalogue |
| Project version | Standard Version of Project |
| Proposition 65 | Cancer and Reproductive Harm |
| Rear cover | Standard cover for pump |
| ROTATION | Product with clockwise rotation |
| Screws | Screws standard |
| Seals | Standard seal |
| Single Stage Family | Gr2 Pump |
| Slash separator | Slash |
| Valve setting | without setting |
11234293: frequently asked questions
When can 11234293 be shipped?
11234293 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11234293 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11234293 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11234293, subject to availability and destination.
