Danfoss 11233164

TRIPLE GEAR PUMP=GR3+GR2+GR1

MPN: 11233164
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11233164?

Danfoss TRIPLE GEAR PUMP=GR3+GR2+GR1, manufacturer part number 11233164. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A_FAMILY GR3+2+1	SNW3NN+SNW2NN+SNP1NN
B: 1st stage displacement	Displacement 30cc
C: 2nd stage displacement	Displacement 17 cc
D: 3rd stage displacement	Displacement 3,2cc
E: Rotation	Left rotation
F: Project version	Intermediate flange all stages
G_FLANGE GR1+1+1	Slash
G: Mounting flange	SAE B-Pilot D101,6+2 holes for bolts
H: Drive gear	Spline SAE J498-13T-16/32-Dp Class 1FIT-for flange SAE B+Rear spline DIN 5482 22x19xL16,5 SC47
I: Rear cover	Std Cover for pump
J: 1st stage inlet size	27x55xM8
K: 1st stage outlet size	18x55xM8
L: 1st stage ports position	Std from catalogue
M: 2nd stage inlet size	20x40xM6
N: 2nd stage outlet size	15x35xM6
O-Ring, Inside Diameter	Slash
O: 2nd stage ports position	Std from catalogue
OC DELIMITER (-)	-
P: 3rd stage inlet size	13x30xM6
Proposition 65	Cancer and Reproductive Harm
Q: 3rd stage outlet size	8x30xM6
R: 3rd stage ports position	Std from catalogue
S: Seals	Std seal
Slash separator	Slash
T: Screws	Screws standard
U: Valve setting	without setting
V: Mark type	Std Sauer Danfoss Marking
W: Mark position	Std mark position
