Danfoss 11228654

GEAR PUMP GR2 FIXED DISPL WITH VALVE

MPN: 11228654
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11228654?

Danfoss GEAR PUMP GR2 FIXED DISPL WITH VALVE, manufacturer part number 11228654. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	2
Displacement	Displacement 6,0 cc
Drive gear	SAE J498-13T-16/32
E_VALVE GROUP2	Relief valve with external drain
F_DRAIN GROUP2	Standard
Inlet size	20x40xM6
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	SAE B pilot D101,6+2 holes
O-Ring, Inside Diameter	Slash
Outlet size	15x35xM6
Ports position	Port type Bx-Bx for flange SAE-A as per catalogue (inverted std. position from flange to cover) LCX
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for pump per relief valve with external drain 3/4-16UNF-2B
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Hi.Torque Pump-Ext.dr.RV
Slash separator	Slash
Valve setting	Setting relief valve, velocity of product per checked setting 1500 rpm and pressure 80 bar with oil ISO VG68 a 40°-50°C
