Danfoss 11227088

PVBS256-SPOOL-C95/F95/F95/C95-FLA

MPN: 11227088
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11227088?

Danfoss PVBS256-SPOOL-C95/F95/F95/C95-FLA, manufacturer part number 11227088. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A->T Control Type	Flow
A->T Flow Rate	95
A->T Function in Neutral	Blocked (Closed)
B->T Control Type	Flow
B->T Flow Rate	95
B->T Function in Neutral	Blocked (Closed)
Certification	ISO13849 Compliant
Ex Application	N/A
Float Direction	A Port
Marking	N/A
Minimum Float Position	10
Nominal Diameter	Standard
Nominel Max Position A	12
Nominel Max Position B	10
P-> A Flow Rate	95
P-> B Flow Rate	95
P->A Control Type	Flow
P->B Control Type	Flow
Pilot Pressure Full Stroke	19.0 bar
Pilot Pressure Neutral	5.0 bar
Pressure Control P->A	N/A
Pressure Control P->B	N/A
Primer	N/A
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Spool Characteristic A	Progressive
Spool Characteristic B	Progressive
Spool Data	N/A
Spool Deadband	1.7
Spool Interface	PVB128/PVB256
Spool Option A	Spring Package
Spool Option B	N/A
