Danfoss 11224613

TANDEM=GEAR PUMP GR3+GEAR PUMP GR1

MPN: 11224613
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11224613?

Danfoss TANDEM=GEAR PUMP GR3+GEAR PUMP GR1, manufacturer part number 11224613. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.3+1 family	SNW3NN + SNI1NN
B: 1st stage displacement	Displacement 75cc
C: 2nd stage displacement	Displacement 7,8cc
D: Rotation	Product with clockwise rotation
E: Project version	With intermediate flange
F: Mounting flange	Flange with pilot D.60,3 and 4 holes for bolts
G: Drive gear	Taper 1:8 - M16 x 1,5 - Key = 4,79 ; rear spline DIN 5482 22 x 19 L=16,5 CO43
H: Rear cover	Cover for pump per relief valve
I: 1st stage inlet size	36x62xM10
J: 1st stage outlet size	27x51xM10
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	12x26xM5
M: 2nd stage outlet size	12x26xM5
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	Setting relief valve, velocity of product per checked setting 1500 rpm and pressure 160 bar with oil ISO VG68 a 40°-50°C
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Position Marking standard
Slash separator	Slash
