Danfoss 11201383

PVBS256-SPOOL-O180/F180/F65/O65-N

MPN: 11201383
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11201383?

Danfoss PVBS256-SPOOL-O180/F180/F65/O65-N, manufacturer part number 11201383. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A->T Control Type	Flow
A->T Flow Rate	180
A->T Function in Neutral	Drained (Throttle Open)
B->T Control Type	Flow
B->T Flow Rate	65
B->T Function in Neutral	Drained (Throttle Open)
Certification	ISO13849 Compliant
Ex Application	N/A
Float Direction	N/A
Marking	N/A
Minimum Float Position	N/A
Nominal Diameter	Standard
Nominel Max Position A	10
Nominel Max Position B	10
P-> A Flow Rate	180
P-> B Flow Rate	65
P->A Control Type	Flow
P->B Control Type	Flow
Pilot Pressure Full Stroke	5.0 bar
Pilot Pressure Neutral	2.0 bar
Pressure Control P->A	N/A
Pressure Control P->B	N/A
Primer	N/A
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Spool Characteristic A	Progressive
Spool Characteristic B	Progressive
Spool Data	N/A
Spool Deadband	1.7
Spool Interface	PVB128/PVB256
Spool Option A	Tensionbar
Spool Option B	N/A
