Danfoss 11196127

TANDEM GEAR PUMP GR3 FIXED DISPL

MPN: 11196127
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11196127?

Danfoss TANDEM GEAR PUMP GR3 FIXED DISPL, manufacturer part number 11196127. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.3+3 family	SNW3NN + SNQ3NN
B: 1st stage displacement	Displacement 48cc
C: 2nd stage displacement	Displacement 26cc
D: Rotation	Left rotation
E: Project version	Without intermediate flange
F: Mounting flange	Outrig. 01 taper1:8-key 4x7,5
G: Drive gear	Taper 1:8-M14x1,5-Key 4
H: Rear cover	Standard Cover for pump
I: 1st stage inlet size	31x30,18x58,72x7/16-14UNC
J: 1st stage outlet size	25x26,19x52,37x3/8-16UNC
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	25x26,19x52,37x3/8-16UNC
M: 2nd stage outlet size	18,5x22,23x47,63x3/8-16UNC
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without valve
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Position Marking standard
Slash separator	Slash
