Danfoss 11189095

PROTOTYPE GEAR PUMP GR3 FIXED DISPL

MPN: 11189095
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11189095?

Danfoss PROTOTYPE GEAR PUMP GR3 FIXED DISPL, manufacturer part number 11189095. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

B: Displacement	Displacement 26 cc
C: Rotation	Product with clockwise rotation
D_SIZE GROUP3	Group3-from 16 to 90cc displ
D: Project version	Standard Version of Project
E_VALVE GROUP3	Without valve
E: Mounting flange	Flange with pilot D.82,55 and 2 holes for bolts
F_DRAIN GROUP3	Standard or no drain
F: Drive gear	Splined SAE J498-13T-16/32-Dp Class 1FIT - for flange SAE 'A' SC09
G: Rear cover	Standard cover for pump
H: Inlet size	25x26,19x52,37x3/8-16UNC
I: Outlet size	18,5x22,23x47,63x3/8-16UNC
J: Ports position	Standard from catalogue
K: Seals	Standard seal
L: Screws	Screws standard
M: Valve setting	without setting
N: Mark type	Standard Marking
O-Ring, Inside Diameter	Slash
O: Mark position	Position Marking standard
Proposition 65	Cancer and Reproductive Harm
Slash separator	Slash
