Danfoss 11183170

TRIPLE GEAR PUMP GR3 FIXED DISPL

MPN: 11183170
Category: GearMe modular three stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11183170?

Danfoss TRIPLE GEAR PUMP GR3 FIXED DISPL, manufacturer part number 11183170. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Triple Gr.3+3+3 family	SNW3NN+SNO3NN+SNQ3NN
B: 1st stage displacement	Displacement 55cc
C: 2nd stage displacement	Displacement 55cc
D: 3rd stage displacement	Displacement 33cc
E: Rotation	Left rotation
F: Project version	Std without interm.flange
G_FLANGE GR1+1+1	Slash
G: Mounting flange	Pilot D50,8+4 holes for bolts(98,4x128,1)
H: Drive gear	Taper 1:8-M14x1,5-Key 4+Rear spline DIN 5482 22x19xL16,5 CO41-CO42
I: Rear cover	Std Cover for pump
J: 1st stage inlet size	36x1-1/4 GAS
K: 1st stage outlet size	27x1 GAS
L: 1st stage ports position	Std from catalogue
M: 2nd stage inlet size	27x1 GAS
N: 2nd stage outlet size	27x1 GAS
O-Ring, Inside Diameter	Slash
O: 2nd stage ports position	Std from catalogue
OC DELIMITER (-)	-
P: 3rd stage inlet size	27x1 GAS
Proposition 65	Cancer and Reproductive Harm
Q: 3rd stage outlet size	27x1 GAS
R: 3rd stage ports position	Std from catalogue
S: Seals	Std seal
Slash separator	Slash
T: Screws	Screws standard
U: Valve setting	without valve
V: Mark type	Std Sauer Danfoss Marking
W: Mark position	Std mark position
