Danfoss 11182255
TANDEM GEAR PUMP GR2 FIXED DISPL
- MPN
- 11182255
- Category
- GearMe modular two stage
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 11182255?
Danfoss TANDEM GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11182255. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| A: Tandem Gr.2 family | SNW2NN+SNP2NN |
| B: 1st stage displacement | Displacement 22 cc |
| C: 2nd stage displacement | Displacement 19 cc |
| D: Rotation | Product with clockwise rotation |
| E: Project version | Standard ( without intermediate flange ) |
| F: Mounting flange | Flange SAE A, pilot D.82,55 and 2 holes for bolts |
| G: Drive gear | Splined SAE J498-9T-16/32-Dp Class 1FIT - ( rear tang 8 x 17,46 x L=6,5 ) (type 46) |
| H: Rear cover | Cover for pump with holes M5 |
| I: 1st stage inlet size | 3/4 GAS |
| J: 1st stage outlet size | 1/2 GAS |
| K: 1st stage ports position | Standard from catalogue |
| L: 2nd stage inlet size | 3/4 GAS |
| M: 2nd stage outlet size | 1/2 GAS |
| N: 2nd stage ports position | Standard from catalogue |
| O-Ring, Inside Diameter | Slash |
| O: Seals | Standard seal |
| OC DELIMITER (-) | - |
| P: Screws | Standard screws |
| Proposition 65 | Cancer and Reproductive Harm |
| Q: Valve setting | without setting |
| R: Mark type | Special Mallaghan Marking |
| S: Mark position | Std Position Marking |
| Slash separator | Slash |
11182255: frequently asked questions
When can 11182255 be shipped?
11182255 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11182255 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11182255 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11182255, subject to availability and destination.
