Danfoss 11181002

GEAR PUMP GR3 FIXED DISPL

MPN: 11181002
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11181002?

Danfoss GEAR PUMP GR3 FIXED DISPL, manufacturer part number 11181002. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

B: Displacement	Displacement 44 cc
C: Rotation	Product with counter-clockwise rotation
D_SIZE GROUP3	Group3-from 16 to 90cc displ
D: Project version	Standard Version of Project
E_VALVE GROUP3	Without valve
E: Mounting flange	Flange pilot D50,8 and 4 holes for bolts(98,4x128,1)with special shaft seal slot (BAT)
F_DRAIN GROUP3	Standard or no drain
F: Drive gear	Parallel drive SAE diam. 22,225 L=25,4 , Key 6,375 x 6,375 x 25,4 , rear spline DIN 5482 22x19 L=16,5 CI47
G: Rear cover	Not assigned (with intermediate flange instead cover)
H: Inlet size	27x1-5/8-12UN
I: Outlet size	23,5x1-5/16-12UN
J: Ports position	Standard from catalogue
K: Seals	Standard seal
L: Screws	Screws standard
M: Valve setting	without setting
N: Mark type	Standard Marking
O-Ring, Inside Diameter	Slash
O: Mark position	Position Marking standard
Proposition 65	Cancer and Reproductive Harm
Slash separator	Slash
