Home / Danfoss (Drives) / Compensated directional control valves / Danfoss 11178733

Danfoss 11178733

PVBS256-SPOOL-C320/F320/F320/C320-N

MPN: 11178733
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11178733?

Danfoss PVBS256-SPOOL-C320/F320/F320/C320-N, manufacturer part number 11178733. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A->T Control Type	Flow
A->T Flow Rate	320
A->T Function in Neutral	Blocked (Closed)
B->T Control Type	Flow
B->T Flow Rate	320
B->T Function in Neutral	Blocked (Closed)
Certification	ISO13849 Compliant
Ex Application	N/A
Float Direction	N/A
Marking	N/A
Minimum Float Position	N/A
Nominal Diameter	Standard
Nominel Max Position A	10
Nominel Max Position B	10
P-> A Flow Rate	320
P-> B Flow Rate	320
P->A Control Type	Flow
P->B Control Type	Flow
Pilot Pressure Full Stroke	5.0 bar
Pilot Pressure Neutral	2.0 bar
Pressure Control P->A	N/A
Pressure Control P->B	N/A
Primer	N/A
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Spool Characteristic A	Progressive
Spool Characteristic B	Progressive
Spool Data	N/A
Spool Deadband	1.7
Spool Interface	PVB128/PVB256
Spool Option A	Tensionbar
Spool Option B	N/A

11178733: frequently asked questions

When can 11178733 be shipped?

11178733 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11178733 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11178733 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11178733, subject to availability and destination.
