Danfoss 11176702

PVPV256-INLET-UNF-PILOTDUMP-PVLP

MPN: 11176702
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11176702?

Danfoss PVPV256-INLET-UNF-PILOTDUMP-PVLP, manufacturer part number 11176702. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Side Interface	Threaded Ports
Additional Feature	N/A
B Side Interface	N/A
Bottom Interface	Mounting Feet A/B
Certification	N/A
CF Out Nominel Flow	N/A
CF Port Placement	N/A
CF Port Size	N/A
Continous System Pressure	350
Customer Specific Attributes	N/A
Dynamic Response (Damping)	M6 Orifice Facility LS
Ex Application	Ex h I/II
Extra LS Port Placement	N/A
Extra LS Port Size	N/A
Extra Pump Port Placement	N/A
Extra Pump Port Size	N/A
Extra Tank Port Placement	N/A
Extra Tank Port Size	N/A
Full flow dump Facility	N/A
Gauge Port Pilot Pres Location	Top
Gauge Port Pilot Pressure Size	#4 - 7/16-20 UNF
Gauge Port Pump Pressure Size	#8 - 3/4-16 UNF
Gauge Port Tank Pressure Size	#4 - 7/16-20 UNF
HPCO Port Placement	N/A
HPCO Port Size	N/A
Inlet Compensator/Unloader	N/A
Left Interface	Threaded Ports
LS Boost Facility	N/A
LS Dump Facility	N/A
LS Port Placement	A
LS Port Size	#6 - 9/16-18 UNF
LS Relief	N/A
LX Port Placement	N/A
LX Port Size	N/A
Marking	N/A
Maximum System Pressure Peaks	400
Module Type	Start Module
Mounting Thread Size	M12
Nominel Flow	600
Pilot Dump Facility	SDC08-3
Pilot Pressure	13.5 (PVE)
Pilot Pressure Accumulator Por	N/A
Port Connection Type	SAE [ISO 11926-1]
Pressure Relief Valve	No
Primer	Passivation - Transparent
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Pump Configuration	Closed Center/Variable
Pump Port Placement	Left
Pump Port Pressure Location	Top
Pump Port Size	1 7/8-12 UNF
PVPC Facility	N/A
Right Interface	PVG256-Flat-T0
Shock Valve Facility	2 x PVLP63 Cavity
T0 Facility	T0 Required
T0 Port Placement	N/A
T0 Port Size	N/A
Tank Port Placement	Left
Tank Port Pressure Location	Top
Tank Port Size	1 7/8-12 UNF
Tie Rod Length	4
Tie Rod Type Left	N/A
Tie Rod Type Right	Threaded Hole
Top Interface	Threaded Ports
Valve Family	PVG128-256
Width	62
