Home / Danfoss (Drives) / GearMe single stage / Danfoss 11176387

Danfoss 11176387

GEAR PUMP GR2 FIXED DISPL

MPN: 11176387
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11176387?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11176387. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	2
Displacement	Displacement 14 cc
Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT -SC06
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Standard
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	SAE A pilot D82,55+2 bolts+inl
O-Ring, Inside Diameter	Slash
Outlet size	15x35xM6
Ports position	Port type Bx-Bx for flange SAE-A as per catalogue (inverted std. position from flange to cover) LCX
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for pump
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Pump
Slash separator	Slash
Valve setting	without setting
