Home / Danfoss (Drives) / GearMe single stage / Danfoss 11175673

Danfoss 11175673

GEAR PUMP GR2 FIXED DISPL

MPN: 11175673
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11175673?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11175673. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	2
Displacement	Displacement 25 cc
Drive gear	Splined DIN 5482 B17 x 14 , flange protrusion sb=22 (dr=62/65 SN.2/SH.2) support protrusion ss=1.5 support distance ds=20.5 SC01P
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Standard
Inlet size	23,5x40xM8
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Flange with pilot D.36,5 and 4 holes for bolts with special shaft seal slot (BAT)
O-Ring, Inside Diameter	Slash
Outlet size	20x40xM8
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for pump
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Product with VITON seals (LCG)
Single Stage Family	Gr2 Pump
Slash separator	Slash
Valve setting	without setting

11175673: frequently asked questions

When can 11175673 be shipped?

11175673 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11175673 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11175673 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11175673, subject to availability and destination.
