Danfoss 11175337
GEAR MOTOR GR2 FAN DRIVE FIXED DISPL
- MPN
- 11175337
- Category
- Gear motors
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 11175337?
Danfoss GEAR MOTOR GR2 FAN DRIVE FIXED DISPL, manufacturer part number 11175337. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| D_SIZE GROUP2 | 2 |
| Displacement | Displacement 22 cc |
| Drive gear | Taper 1:5 - M12 x 1,25 - Key = 3 CO02 |
| E_VALVE GROUP2 | Proportional Valve with internal drain and anti-cavitation check valve on the bearings |
| F_DRAIN GROUP2 | Standard |
| Inlet size | 1-1/16-12UN |
| Mark position | Position Marking standard (on the top in relation to drive gear) |
| Mark type | Standard Marking |
| Mounting flange | Flange with pilot Ø80 mm and 4 holes for bolts |
| O-Ring, Inside Diameter | Slash |
| Outlet size | 1-1/16-12UN |
| Ports position | Standard from catalogue |
| Project version | Standard with precharge seal on cover |
| Proposition 65 | Cancer and Reproductive Harm |
| Rear cover | Cover for motor per proportional valve and axial drain 9/16-18UNF-2B |
| ROTATION | Product with clockwise rotation |
| Screws | Screws standard |
| Seals | Standard seal |
| Single Stage Family | Gr2 Bidir.Motor+PRV Valve |
| Slash separator | Slash |
| Valve setting | Setting proportional valve, type of connector 12 DT Volt and pressure 170 bar with oil ISO VG68 a 40°-50°C |
11175337: frequently asked questions
When can 11175337 be shipped?
11175337 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 11175337 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 11175337 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11175337, subject to availability and destination.
