Danfoss 11175240

TANDEM GEAR PUMP GR2 FIXED DISPL

MPN: 11175240
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11175240?

Danfoss TANDEM GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11175240. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.2 family	SNW2NN+SNP2NN
B: 1st stage displacement	Displacement 22 cc
C: 2nd stage displacement	Displacement 19 cc
D: Rotation	Product with clockwise rotation
E: Project version	Standard ( without intermediate flange )
F: Mounting flange	Flange with pilot D.36,5 and 4 holes for bolts
G: Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4 , (Rear shaft tang)
H: Rear cover	Cover for pump with holes M5
I: 1st stage inlet size	1 GAS
J: 1st stage outlet size	3/4 GAS
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	3/4 GAS
M: 2nd stage outlet size	1/2 GAS
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without setting
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Std Position Marking
Slash separator	Slash

11175240: frequently asked questions

When can 11175240 be shipped?

11175240 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11175240 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11175240 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11175240, subject to availability and destination.
