Home / Danfoss (Drives) / Compensated directional control valves / Danfoss 11167347

Danfoss 11167347

PVBS32-SPOOL-O10/F15/F15/O10-N

MPN: 11167347
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 11167347?

Danfoss PVBS32-SPOOL-O10/F15/F15/O10-N, manufacturer part number 11167347. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A->T Control Type	Flow
A->T Flow Rate	10
A->T Function in Neutral	Drained (Throttle Open)
B->T Control Type	Flow
B->T Flow Rate	10
B->T Function in Neutral	Drained (Throttle Open)
Certification	ISO13849 Compliant
Ex Application	N/A
Float Direction	N/A
Marking	N/A
Minimum Float Position	N/A
Nominal Diameter	Standard
Nominel Max Position A	7.2
Nominel Max Position B	7.2
P-> A Flow Rate	15
P-> B Flow Rate	15
P->A Control Type	Flow
P->B Control Type	Flow
Pilot Pressure Full Stroke	13.0 bar
Pilot Pressure Neutral	4.5 bar
Pressure Control P->A	N/A
Pressure Control P->B	N/A
Primer	N/A
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Spool Characteristic A	Linear
Spool Characteristic B	Linear
Spool Data	N/A
Spool Deadband	0.8
Spool Interface	PVB32
Spool Option A	Tensionbar
Spool Option B	Plug

11167347: frequently asked questions

When can 11167347 be shipped?

11167347 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11167347 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11167347 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11167347, subject to availability and destination.
