Danfoss 11160953

PVBS16-SPOOL-O5/F5/F2.5/O2.5-FLB-ASM-PVE

MPN: 11160953
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11160953?

Danfoss PVBS16-SPOOL-O5/F5/F2.5/O2.5-FLB-ASM-PVE, manufacturer part number 11160953. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A->T Control Type	Flow
A->T Flow Rate	5
A->T Function in Neutral	Drained (Throttle Open)
B->T Control Type	Flow
B->T Flow Rate	3
B->T Function in Neutral	Drained (Throttle Open)
Certification	ISO13849 Compliant
Ex Application	N/A
Float Direction	B Port
Marking	N/A
Minimum Float Position	6
Nominal Diameter	Standard
Nominel Max Position A	5
Nominel Max Position B	5
P-> A Flow Rate	5
P-> B Flow Rate	3
P->A Control Type	Flow
P->B Control Type	Flow
Pilot Pressure Full Stroke	5.5 bar
Pilot Pressure Neutral	3.0 bar
Pressure Control P->A	N/A
Pressure Control P->B	N/A
Primer	N/A
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
Spool Characteristic A	Progressive
Spool Characteristic B	Progressive
Spool Data	N/A
Spool Deadband	1.2
Spool Interface	PVB16
Spool Option A	Tensionbar
Spool Option B	Plug
