Danfoss 11156502

GEAR MOTOR GR2 FAN DRIVE WITH VALVE

MPN: 11156502
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11156502?

Danfoss GEAR MOTOR GR2 FAN DRIVE WITH VALVE, manufacturer part number 11156502. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 14 cc
Drive gear	Taper 1:8 - M12 x 1,25 - Key = 4 CO01
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking + Customer Code (DQST018)
Mounting flange	Flange SAE A, pilot Ø82,55 mm and 2 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	7/8-14UNF
Ports position	Standard from catalogue
Project version	Generation II
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for motor per proportional valve and vertical drain 9/16-18UNF-2B 180°
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Mot.ISIS-CI Cov+In7/8-14;V.dr.
Slash separator	Slash
Valve setting	Setting proportional valve, type of connector 12 DT Volt and pressure 110 bar with oil ISO VG68 a 40°-50°C

11156502: frequently asked questions

When can 11156502 be shipped?

11156502 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11156502 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11156502 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11156502, subject to availability and destination.
