Danfoss 11154156

GEAR MOTOR GR2 FAN DRIVE WITH VALVE

MPN: 11154156
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11154156?

Danfoss GEAR MOTOR GR2 FAN DRIVE WITH VALVE, manufacturer part number 11154156. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	2
Displacement	Displacement 14 cc
Drive gear	Spline DIN 5482 B17 x 14 L=14 SC02
E_VALVE GROUP2	Proportional Valve with internal drain and anti-cavitation check valve on the bearings
F_DRAIN GROUP2	Inlet on body - Outlet on body - Drain on cover in vertical position driven gear side
Inlet size	Without inlet
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Outrigger Bearing Type 02 with taper shaft 1:5 - M14x1,5 - Key=4 mm andspecial shaft seal BABSL (75 NBR/106200) (RZB)
O-Ring, Inside Diameter	Slash
Outlet size	20x40xM6
Ports position	Standard from catalogue
Project version	Generation II
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for motor per proportional valve and vertical drain 9/16-18UNF-2B
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Mot.ISIS-CI Cov+In7/8-14;V.dr.
Slash separator	Slash
Valve setting	Setting proportional valve, type of connector 24 DT Volt and pressure 190 bar with oil ISO VG68 a 40°-50°C

11154156: frequently asked questions

When can 11154156 be shipped?

11154156 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11154156 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11154156 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11154156, subject to availability and destination.
