Danfoss 11148707

GEAR MOTOR GR2 UNIDIRECT FIXED DISPL

MPN: 11148707
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11148707?

Danfoss GEAR MOTOR GR2 UNIDIRECT FIXED DISPL, manufacturer part number 11148707. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 6,0 cc
Drive gear	Spline DIN 5482 B17 x 14 L=14 SC02
E_VALVE GROUP2	Without Valve
F_DRAIN GROUP2	Standard
Inlet size	15x35xM6
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Outrigger Bearing Type 02 with taper shaft 1:5 - M14x1,5 - Key=4 mm andspecial shaft seal BABSL (75 NBR/106200) (RZB)
O-Ring, Inside Diameter	Slash
Outlet size	20x40xM6
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover Pump+Thd M5-w/o arrow
ROTATION	Product with clockwise rotation
Screws	Product with galvanized assembly screws ( +nuts, washers or cap nuts if listed on the Bill of Material )
Seals	Standard seal
Slash separator	Slash
Valve setting	without setting
