Danfoss 11126567

GEAR MOTOR GR2 UNIDIRECT WITH VALVE

MPN: 11126567
Category: Gear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11126567?

Danfoss GEAR MOTOR GR2 UNIDIRECT WITH VALVE, manufacturer part number 11126567. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

D_SIZE GROUP2	Group 2:from 3 to 28 cc
Displacement	Displacement 19 cc
Drive gear	Taper 1:5 - M12 x 1,25 - Key = 3 CO02
E_VALVE GROUP2	Anti-cavitation check valve on the bearings
F_DRAIN GROUP2	Standard
Inlet size	20x40xM6
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	SCANIA Marking
Mounting flange	Flange with pilot Ø80 mm and 4 holes for bolts
O-Ring, Inside Diameter	Slash
Outlet size	27x55xM8
Ports position	Port type Bx-Bx in the center of the body (B)
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Standard cover for pump
ROTATION	Product with counter-clockwise rotation
Screws	Screws standard
Seals	With VITON sh.seal+Dust Cove
Slash separator	Slash
Valve setting	without setting
