Danfoss 11117447

GEAR PUMP GR2 FIXED DISPL

MPN: 11117447
Category: GearMe single stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11117447?

Danfoss GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11117447. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Displacement	Displacement 6,0 cc
Drive gear	Spline DIN 5482 B17 x 14 L=14 SC02
Inlet size	1-1/16-12UN
Mark position	Position Marking standard (on the top in relation to drive gear)
Mark type	Standard Marking
Mounting flange	Outrigger Bearing Type 04 with taper shaft 1:5 - M12x1,25 - Key=3 mm
O-Ring, Inside Diameter	Slash
Outlet size	7/8-14UNF
Ports position	Standard from catalogue
Project version	Standard Version of Project
Proposition 65	Cancer and Reproductive Harm
Rear cover	Cover for pump with holes M5
ROTATION	Product with clockwise rotation
Screws	Screws standard
Seals	Standard seal
Single Stage Family	Gr2 Pump
Slash separator	Slash
Valve setting	without setting

11117447: frequently asked questions

When can 11117447 be shipped?

11117447 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11117447 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11117447 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11117447, subject to availability and destination.
