Home / Danfoss (Drives) / GearMe modular two stage / Danfoss 11112616

Danfoss 11112616

TANDEM GEAR PUMP GR2 FIXED DISPL

MPN: 11112616
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11112616?

Danfoss TANDEM GEAR PUMP GR2 FIXED DISPL, manufacturer part number 11112616. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.2 family	SNW2NN+SNP2NN
B: 1st stage displacement	Displacement 8,0 cc
C: 2nd stage displacement	Displacement 8,0 cc
D: Rotation	Product with clockwise rotation
E: Project version	With SAE intemediate flange
F: Mounting flange	Flange SAE A, pilot D.82,55 and 2 holes for bolts
G: Drive gear	Splined SAE J498-9T-16/32-Dp Class 1FIT - rear spline DIN 5482 - 17 x 14 L=14 (type 36 vers.2)
H: Rear cover	Standard cover for pump
I: 1st stage inlet size	1-1/16-12UN
J: 1st stage outlet size	7/8-14UNF
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	1-1/16-12UN
M: 2nd stage outlet size	7/8-14UNF
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without setting
R: Mark type	Standard Marking + Customer Code (DQST018)
S: Mark position	Mark the product on the bottom in relation to the drive gear (LFR)
Slash separator	Slash

11112616: frequently asked questions

When can 11112616 be shipped?

11112616 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11112616 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11112616 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11112616, subject to availability and destination.
